Standard: API SPEC 5L ISO 3183 Uses: For conveying gas, water and oil either in the oil or natural gas industries Dimension:Weld: ¦µ21.3~660x1~20mm Chemical Analysis (%): ....
Mechanical Properities:
| Standard |
Class |
Grade |
|
Yield strength not less than (MPa) |
Tensile strength (MPa) |
Elongation(%) |
Y.S/T.S |
| API SPEC 5L ISO 3183 |
PSL1 |
L245B |
min |
245 |
415 |
b |
- |
| L290X42 |
min |
290 |
415 |
b |
- |
| L320X46 |
min |
320 |
435 |
b |
- |
| L360X52 |
min |
360 |
460 |
b |
- |
| L390X56 |
min |
390 |
490 |
b |
- |
| L415X60 |
min |
415 |
520 |
b |
- |
| L450X60 |
min |
450 |
535 |
b |
- |
| L485X70 |
min |
485 |
570 |
b |
- |
| PSL2 |
L245N BN |
min |
245 |
415 |
b |
- |
| L245M BM |
max |
450 |
760 |
b |
0.93 |
| L290NX42N |
min |
290 |
415 |
b |
- |
| L290MX42M |
max |
495 |
760 |
b |
0.93 |
| L320NX46N |
min |
320 |
435 |
b |
- |
| L320MX46M |
max |
525 |
760 |
b |
0.93 |
| L360NX52N |
min |
360 |
460 |
b |
- |
| L360MX52M |
max |
530 |
760 |
b |
0.93 |
| L390NX56N |
min |
390 |
490 |
b |
- |
| L390MX56M |
max |
545 |
760 |
b |
0.93 |
| L415NX60N |
min |
415 |
520 |
b |
- |
| L415MX60M |
max |
565 |
760 |
b |
0.93 |
| L450MX65M |
min |
450 |
535 |
b |
- |
| max |
600 |
760 |
b |
0.93 |
| L485MX70M |
min |
485 |
570 |
b |
- |
| max |
635 |
760 |
b |
0.93 |
| L555MX80M |
min |
555 |
625 |
b |
- |
| max |
705 |
825 |
b |
0.93 |
Toughness:
Note:(1)The values in the table be suitable for the full size standard sample.
(2) The values inside bracket is the minimum single value, outside bracket is the average value.
(3) Test Temperature: 0¡ãC.
Available Dimension Range: ¦µ21.3~660*1~20mm
|
